Cutting power
(A)
|
Plate thickness
(mm)
|
Speed
(mm/min)
|
Arc voltage value |
Air pressure
(Mpa)
|
Nozzle model |
Positioning height
(mm)
|
Piercing time
(s)
|
| 120A | 4 | 4500 | 155 | 0.55±0.3 | 40216 | 6 | 0 |
| 6 | 3800 | 155 | 0.55±0.3 | 40216 | 6 | 0 | |
| 8 | 3100 | 155 | 0.55±0.3 | 40216 | 6 | 0.5 | |
| 10 | 2300 | 155 | 0.55±0.3 | 40216 | 6 | 0.5 | |
| 12 | 2100 | 155 | 0.55±0.3 | 40216 | 6 | 0.5 | |
|
Cutting power
(A)
|
Plate thickness
(mm)
|
Speed
(mm/min)
|
Arc voltage value |
Air pressure
(Mpa)
|
Nozzle model |
Positioning height
(mm)
|
Piercing time
(s)
|
| 200A | 14 | 2500 | 155 | 0.55±0.3 | 40220 | 8 | 0.3 |
| 16 | 2100 | 160 | 0.55±0.3 | 40220 | 8 | 0.3 | |
| 20 | 1700 | 163 | 0.55±0.3 | 40220 | 8 | 0.5 | |
| 25 | 1300 | 165 | 0.55±0.3 | 40220 | 8 | 0.8 | |
| 30 | 1000 | 165 | 0.55±0.3 | 40220 | 8 | 1.2 | |
|
Cutting power
(A)
|
Plate thickness
(mm)
|
Speed
(mm/min)
|
Arc voltage value |
Air pressure
(Mpa)
|
Nozzle model |
Positioning height
(mm)
|
Piercing time
(s)
|
| 300A | 30 | 1300 | 165 | 0.55±0.3 | 40224 | 10 | 1 |
| 35 | 1050 | 165 | 0.55±0.3 | 40224 | 10 | 1.4 | |
|
Cutting power
(A)
|
Plate thickness
(mm)
|
Speed
(mm/min)
|
Arc voltage value |
Air pressure
(Mpa)
|
Nozzle model |
Positioning height
(mm)
|
Piercing time
(s)
|
| 400A | 30 | 1350 | 165 | 0.55±0.3 | 40226 | 10 | 1.2 |
| 35 | 1250 | 165 | 0.55±0.3 | 40226 | 10 | 1.4 | |
| 40 | 800 | 170 | 0.55±0.3 | 40226 | 10 | 2 | |
| The above data is for reference only, and can be adjusted in real time according to the on-site cutting situation. | |||||||
